Product introduction

When you require stable power in outdoor or mobile work environments, the pure sine wave inverter (model SBE3012/3024) provides an efficient and safe power conversion solution. This device converts DC power from a battery into clean, stable AC power for home use, boasting a 3000W output. Its pure sine wave output is clean and smooth, effectively suppressing voltage fluctuations and power interference, ensuring the safe operation of connected precision equipment. It is widely applicable to large machinery and commercial sectors, including heavy-duty equipment, lighting systems, and high-power power tools. The compact design features an aluminum-plastic composite shell for enhanced heat dissipation and multiple AC output sockets to support simultaneous multi-load connections. This product also features comprehensive safety protection mechanisms, including high/low voltage protection, high temperature protection, short circuit protection, overload protection, and overcurrent protection, ensuring stable and reliable operation under various conditions. Customizable AC output sockets for different countries, as well as logos and shell colors, are available.

Specifications
Inverter SBE parameter specification
Model SBE712/724 SBE1012/1024 SBE2012/2024 SBE3012/3024
Continuous Power 700 W 1000 W 2000 W 3000 W
Input Voltage 12V/24VDC
Output Voltage 230VAC
Peak surge 1400 W 2000 W 4000 W 6000 W
Efficiency >90%
Frequency 60Hz
Otal harmonic distortion
(THD)
<3%
No load current draw <0.8A <1.0A <2.0A <2.5A
Battery low alarm 10.5V±0.5V DC/20.5V±0.5V DC
Battery low shutdown 10.0V±0.5V DC/20.0V±0.5V DC
Over voltage shutdown 16.5V±0.5V DC/33.0V±1.0V DC
Cooling fan Thermally controlled
AC output sockets
USB power port 5V/2.1A
Power output control AC On/Off Switch
Dimensions 291*195*82mm 325*195*82mm 410*244*102mm 475*245*102mm
Net weight
(approximate)
2.2KG 2.4KG 4.6KG 5.5KG
